Hand Valves – Push/Pull
Single Hole Panel Mount



  • Common manual push-pull air valve used in truck/tractors or on converter dollies, semi & full trailers.
  • Dimensions: Height 4.78” – Width 2.56” – Depth 1.75” – Approximate Weight: .92 lbs.
  • REPAIR KIT 176-5
  • Air Piping Diagrams – See Technical / Air Piping Diagrams, multiple diagrams are applicable.
